ATEX Pro 38mm Pole System

The ATEX Pro 38mm system is designed for use in hazardous environments where combustible dust accumulation presents a potential fire or explosion risk.

Typical applications include food manufacturing facilities, grain and flour processing plants, pharmaceutical production environments, recycling facilities, chemical processing plants, battery manufacturing operations, woodworking facilities and other industrial workplaces operating within ATEX-classified areas.

The system allows operators to safely remove combustible dust from elevated surfaces while supporting site compliance and housekeeping programmes.

The system is designed for the safe removal of combustible dust, debris and contamination from elevated surfaces including:

• Roof beams and structural steelwork
• Pipework
• Ducting and ventilation systems
• Cable trays
• Lighting gantries
• Production equipment exteriors
• Wall surfaces
• Storage racking tops
• Ceilings and overhead structures

The kit includes a range of conductive cleaning heads, brushes and specialist tools designed to access difficult-to-reach areas commonly found within industrial facilities.

The ATEX Pro 38mm system features larger diameter poles, increased rigidity and a greater maximum working height compared to the ATEX Lite system.

This provides improved control when working at extended heights and makes the system particularly suitable for larger industrial facilities, warehouses and production environments where regular high-level cleaning is required.

The ATEX Pro 38mm poles are manufactured from 100% conductive carbon fibre using a high modulus 3K 2×2 twill carbon construction.

This provides an excellent balance of strength, durability and rigidity while remaining lightweight enough for safe operation from ground level.

In combustible dust environments, controlling static electricity is an important part of reducing ignition risks.

The conductive carbon fibre construction helps dissipate static charges safely through the cleaning system during operation, supporting safe cleaning practices within hazardous environments.

At the same time, carbon fibre provides the strength and rigidity needed to maintain operator control when cleaning at height.

The ATEX Pro 38mm system includes a comprehensive range of conductive cleaning tools and accessories, including:

• Conductive straight cleaning head
• Conductive 45° cleaning head
• Conductive 90° cleaning head
• Conductive 135° cleaning head
• Conductive flat surface tool
• Conductive large round brush
• Conductive pipe brush
• Conductive crevice tool
• Conductive hose and adaptors
• Padded pole bag
• Hose bag and mesh accessory bag

This allows operators to adapt the system for a wide variety of cleaning challenges within hazardous environments.

The ATEX Pro 38mm system should be paired with an appropriately certified industrial vacuum suitable for the hazardous area classification being cleaned.

SpaceVac commonly recommends compatible systems from the TITAN ATEX and Mercury ACD vacuum ranges, depending on the application and ATEX zone requirements.

Yes.

Additional conductive poles can be added to extend the system’s reach beyond the standard configuration, allowing operators to safely access higher-level structures while remaining on the ground.

No.

The ATEX Pro 38mm system is designed to allow operators to carry out routine high-level cleaning safely from ground level, reducing reliance on ladders, scaffolding, mobile elevated work platforms (MEWPs) and other access equipment.

This can help reduce disruption, improve efficiency and minimise working-at-height risks.

Yes.

The ATEX Pro 38mm system is widely used by industrial cleaning contractors, facilities management teams and specialist service providers operating within hazardous environments.

Its combination of extended reach, lightweight carbon fibre construction and conductive ATEX-certified design makes it particularly well suited to regular commercial and industrial cleaning programmes.

The ATEX Pro 38mm system is designed for use in hazardous dust and gas environments when paired with appropriately certified vacuum equipment.

SpaceVac provides solutions suitable for ATEX gas Zones 0, 1 and 2 and dust Zones 20, 21 and 22, helping operators safely remove combustible dust from elevated surfaces while remaining safely at ground level.

Each ATEX Pro 38mm cleaning pole weighs approximately 290 grams.

This lightweight construction helps reduce operator fatigue during extended cleaning tasks while still providing the rigidity required for effective cleaning at height.
